Automotive(Driving/Safety)

Tantalum Capacitors (Chip Tantalum Capacitors)

Type Features Case code Rated Voltage Capacitance
267 N Series
AEC-Q200 Compliant
High reliability series of Type 267 for Automotive.
Suitable for Automotive Electronics, such as ECU, ABS, Air Bags, and etc.
3216~7343 4.0~35VDC 0.1µF~220µF
271N Series
150℃
150℃ High Temperature Capacitors based on Type 267.
Suitables for ECU in the engine room of Automobile.
3216~7343 4~35VDC 0.1~68µF

Circuit Protection Components (Current Fuses)

Type Features Case code Rated Voltage Rated Current
JAG N Series
AEC-Q200 Compliant
High reliability series of Type JAG for Automotive Electric Control Unit. 3216 32、72
96VDC
0.5~4.0A
KAB N Series
AEC-Q200 Compliant
High reliability series of Type KAB for Automotive Electric Control Unit. 1608
2012
24、32
50VDC
0.5~2.0A(1608)
0.5~2.0A(2012)

Circuit Protection Components (Surge Absorber)

Type Features Case code Rated Voltage Trigger Voltage Clamp voltage
KVA N Series
AEC-Q200 Compliant
High reliability series of Type KVA for Automotive. 1608 24VDC 1000V max. (650V typ.) 200V max. (100V typ.)

※The application classification by use which divided the market and use into four is set up supposing our products being used for a broad use. please be sure to inform to our Sales Department in advance in examination of the use of those other than the indicated use.
