Hearing Aids
Tantalum Capacitors (Chip Tantalum Capacitors)
| Type | Features | Case code | Rated Voltage | Capacitance |
|---|---|---|---|---|
|
251M Series Face-down Terminal  |
Ultra miniature and high capacitance Capacitors with Face-down Terminal Structure. Contribute to miniaturization of the portable multimedia devices. | 1005～3216 | 2.0～35VDC | 0.47～330µF |
|
TCB Conductive Polymer  |
Ultra low ESR Capacitors which using Conductive Polymer with Face-down Terminal Structure. Excellent noise absorption performance on high-frequency circuits. |
1005～3216 | 2.5～10VDC | 4.7～220µF |
Circuit Protection Components （Current Fuses） (Current Fuses)
| Type | Features | Case code | Rated Voltage | Rated Current |
|---|---|---|---|---|
| KAB Miniature  |
Standard thin film type Fuses which is miniature and low profile. Suitable for the portable electronic equipment. |
1608 2012 |
24、32、50VDC | 0.2～6.3A (1608) 0.2～5.0A (2012) |
Circuit Protection Components （Current Fuses） (Surge Absorber)
| Type | Features | Case code | Rated Voltage | Trigger Voltage | Clamp voltage |
|---|---|---|---|---|---|
| KVA Standard  |
ESD protection devices for the circuits of various electronic devices. | 1608 | 24VDC | 1000V max. (650V typ.) | 200V max. (100V typ.) |
※The application classification by use which divided the market and use into four is set up supposing our products being used for a broad use. please be sure to inform to our Sales Department in advance in examination of the use of those other than the indicated use.
