JHC Low Height Product
As battery packs become slimmer and the number of stacked units increases, the mounting area for control boards is becoming smaller, and the electronic components used are required to be smaller and lower profile. To meet this demand, we have developed a product that is a lower profile version of the JHC type used in conventional battery packs. By being completely lead-free, it is an environmentally friendly design. *We have the structure patent of Type JHC. Please beware of imitations.
Rating
| Type | JHC |
|---|---|
| Category Temperature Range | -40～+125℃ |
| Rated Current | 25A、30A、40A、50A、60A、80A、100A、125A |
| Rated Voltage | 84、75 VDC |
| Voltage Drop | 100ｍV max |
| Insulation Resistance | 1000MΩ or more |
| Fusing Characteristics | Fusing within 1 minutes if the current is 250% of rated current. |
| Clearing Characteristics | Breaking voltage：Rated voltgae Breaking current：1000A |
Features
- High current rating was realized because a fuse element and a terminal adopt the structure of one.
- This is small, low-profile, surface-mount type with dimensions of 1173（11.0×7.3×2.6mm）.
- This product features a revised rated voltage and is approximately less than half the height of conventional JHC models.
- Surface temperature rise is 75°C or less when applying rated current. This gives little influence to the peripheral units.
- Alumina ceramics are adopted as a case, original structure is adopted as the inside of a case, and the safety at the time of fusing is improved.
- Suitable for automatic mounting
- Complete lead-free
Application classification
The application classification by use which divided the market and use into four is set up supposing our products being used for a broad use.
Please confirm the application classification by use of each product that you intend to use.
Moreover, please be sure to inform to our Sales Department in advance in examination of the use of those other than the indicated use.
| Market | Application classification by use | Use | Recommendation Type | |
|---|---|---|---|---|
| Outline | Typical example of application | Circuit Protection Components | ||
| High reliability apparatus | 1 | - Apparatus in which advanced safety and reliability are demanded. - Whether failure of the apparatus which cannot maintenance exchange products, and a product is direct for a human life, apparatus which changes or may cause a fatal system failure. |
- Space development apparatus relation (Satellite, Rocket, Artificial Satellite) - Aviation and a defensive system - Atomic power, fire power, and a water-power generation system |
With no relevance |
In-vehicle - Industrial apparatus |
2 | - Apparatus in which reliability is important. - The apparatus in which maintenance exchange of a product is very difficult, and failure of a product influence a human life, or the range of failure is wide range. |
- Vehicles control of transport machines, such as a car, and a railroad, a vessel (Engine control, drive control, brake control) - The operation control system of the Shinkansen and a main artery |
Type JAG N series Type JAJ N series Type JAK N series Type JHC N series Type KAB N series Type KVA N series |
| 3-A | - General electrical equipment designed for use in vehicles but used in the interior environment | - Vehicle indoor loading parts, such as an air-conditioner and car navigation, and in-vehicle communication facility |
Type KAB M series | |
| 3-B | -Apparatus which can maintenance exchange products, and apparatus in which the loss of the system failure is large although failure of a product does not influence a human life, and maintenance engineering is demanded | - Security management system for home/buildings etc. - Control apparatus, such as Industrial use robots and a machine tool etc. |
Type JHC | |
| Apparatus in general | 4 | - The small size and the thin article which applies leading-edge technology positively - The product supposing being used widely in the market for the apparatus which can maintenance exchange products, and apparatus with a partial system failure by failure of product. |
-Smart phone, Mobile phone, Mobile PC (tablet), Electronic dictionary - Desktop PC, Notebook PC, Home network - Amusement apparatus (Pachinko,Game machine) |
Type JAE, Type JAG Type JAJ, Type JAK Type KAB Type KAB T series Type KVA |
