Circuit Protection Components
（Current Fuses）
Circuit Protection Components are used to protect the circuit from overcurrent and overvoltage (static electricity) in the secondary circuits of electronic equipment. Our products are chip type protectors to meet the requirements for high density surface mounting technology, and more suitable for making compact equipment.
Current Fuses
| Type | Features | Case code | Rated Voltage | Rated Current |
|---|---|---|---|---|
| JAE High Pulse Resistance  |
High pulse resitance Fuses using wire material for fuse element. (250% Fusing) |
3216 | 24、32、50VDC | 0.4～8A |
| JAG High Pulse Resistance  |
High pulse resitance Fuses using wire material for fuse element. (200% Fusing) |
3216 | 32、50、72VDC | 0.5～10A |
| JAG N Series AEC-Q200 Compliant  |
High reliability series of Type JAG for Automotive Electric Control Unit. | 3216 | 32、50、72、96VDC | 0.5～10A |
| JAJ High Current  |
Small size and high current are achieved by using frame material for fuse element. (200% fused product) | 3216 | 60VDC | 12.5、16A |
| JAK High Current  |
Small size and high current are achieved by using frame material for fuse element. (250% fused product) | 3216 | 60VDC | 10A～20A |
| JAJ N Series AEC-Q200 Compliant |
It is a small product that can handle high current and can be used as circuit protection against overcurrent in automotive and industrial equipment. | 3216 | 60VDC | 12.5、16A |
| JAK N Series AEC-Q200 Compliant |
It is a small product that can handle high current and can be used as circuit protection against overcurrent in automotive and industrial equipment. | 3216 | 60VDC | 10A～20A |
| JHC High Current  |
High current Fuses using All-in-one fuse element with terminal which suitable for Li-ion rechageable batterypacks. (250% Fusing) |
7358 1173 |
35、60、84、110VDC | 30A～100A |
| KAB Miniature  |
Standard thin film type Fuses which is miniature and low profile. Suitable for the portable electronic equipment. |
1608 2012 |
24、32、50VDC | 0.2～6.3A (1608) 0.2～5.0A (2012) |
| KAB M Series AEC-Q200 Compliant  |
High reliability series of Type KAB for Automotive Interiors. | 1608 2012 |
24、32、50VDC | 0.5～6.3A（1608） 0.5～8.0A（2012） |
| JHC N Series AEC-Q200 Compliant |
Developed for circuit protection against overcurrent in automotive and industrial. It is a product that achives a small size and high current rating while being a surface-mount type. |
7358 | 35、60VDC | 30A～100A |
| KAB N Series AEC-Q200 Compliant |
High reliability series of Type KAB for Automotive Electric Control Unit. | 1608 2012 |
24、32、50VDC | 0.5～2.0A（1608） 0.5～2.0A（2012） |
| KAB T Series High Pulse Resistance  |
High pulse resitance series of Type KAB suitable for protection of Lithium ion battery. | 1608 | 32VDC | 1.6～6.3A |
Surge Absorber
| Type | Features | Case code | Rated Voltage | Trigger Voltage | Clamp voltage |
|---|---|---|---|---|---|
| KVA Standard  |
ESD protection devices for the circuits of various electronic devices. | 1608 | 24VDC | 1000V max. (650V typ.) | 200V max. (100V typ.) |
| KVA N Series AEC-Q200 Compliant  |
High reliability series of Type KVA for Automotive. | 1608 | 24VDC | 1000V max. (650V typ.) | 200V max. (100V typ.) |
Discontinued item
| Discontinued Products | Recommended Replacement | ||
|---|---|---|---|
| Type | Information | Final order period | Type |
| KAH | As for details, please ask our sales dept. | March, 2023 | - |
| KVA 07 | As for details, please ask our sales dept. | March, 2023 | - |
| JAH | As for details, please ask our sales dept. | December, 2024 | - |
| JAHL | As for details, please ask our sales dept. | December, 2024 | - |
